Epoxy resin-based, two component, reaction-dry epoxy primer which contains micaceous iron oxide. It prevents corrosion significantly by creating a barrier on the applied surfaces. Due to the miox pigment inside, it can also be used without applying a top coat.

Surface Preparation&Application
Surfaces should be cleaned of old paint film, oil, dust, dirt, moist, chloride, sulphate salts, rust, rolled mud, tempering, casting - welding burrs etc. which will reduce adhesion on the application surface . Bevel the 90° sharp corners and edges of the application surface and send the surface at minimum Sa2 ½ (ISO 8501-1, SSPC-SP10) degrees, (sand - grid scraper) and prime the scraped surface in 1 to 2 hours with Epoxy Shop Primer. After the primer has fully dried (in 4 to 6 hours), Epoxy Miox Barrier Primer can be applied. Mix the barrier and the hardener in the given ratio until a homogeneous mixture is obtained. Rest the mixture for 2 to 3 minutes for preliminary reaction and apply with the recommended apparatuses. The surface temperature must be minimum 3 Celsius degrees higher than the dew temperature. Application at temperatures near the dew point is not recommended. For the topcoat application wait for 24 hours between coats. Application Temperature: Min. +10°C / Max. + 30 °C

Thinning / Blending Ratio
7A / 1B - Epoxy thinner 5- 10% by weight

Coverage Area
4-5 m²/L or 2-3 m²/kg (60 - -80 µ KFK)

Drying Time
Touch dry in 2-3 hours and hard dry in 24 hours.

Recommended Application Tools
Air - airless spray

20 kg Set (17.5 kg A + 2.5 kg B)

Related Products
Poli HT Kiln Primer VIEW DETAIL
Perla Industrial Primer VIEW DETAIL
Epocrete Coating Primer VIEW DETAIL
Corrox 1K Epoxy Primer VIEW DETAIL

Sitemizin işlemesini sağlamak için çerezler kullanılmaktadır. Detaylı bilgi almak için Polisan Kansai Çerez Aydınlatma Metni'ni incelemenizi rica ederiz.
